America's Cup World Series Portsmouth 2015:
AC45 Tech Gallery: Rudders and Daggerboards


CupInfo Home  |  2017 America's Cup: Teams  |  2017 Schedule  |  Previous Events  |  Feature Articles  |  Books  |  CupStats

AC45 F Yachts Prepare for First Foiling Fleet Races in Portsmouth
New Rudder and Daggerboard Foils

July, 2015



Emirates Team New Zealand's AC45F on the crane in Portsmouth, providing a good view of her appendages.  The ACWS July 25-26 will mark the debut of standardized one-design foils in competition for the AC45F Class, the foiling variant of the AC45.  Note angled daggerboard (in retracted position, right of center) and t-rudder (facing camera at center).  Scroll down for close-ups of the parts.
Photo:2015 ACEA/Gilles Martin-Raget



SoftBank Team Japan's daggerboard seen from outboard looking aft, with foil in retracted position.
Photo:2015 ACEA/Gilles Martin-Raget



Inboard view of daggerboard. Leading edge is painted white. Note the curve in foil shape from mid-span to trailing edge. Photo:2015 ACEA/Gilles Martin-Raget




Image showing upper surface of daggerboard foil.
Photo:2015 ACEA/Gilles Martin-Raget



Artemis shore crew preparing rudders by wet-sanding before mounting. Intersection of vertical and horizontal foils sports torpedo-shaped fairing to mitigate cavitation effects, as adapted on Oracle Team USA's AC72 yacht during the 2013 America's Cup match. Photo:2015 ACEA/Gilles Martin-Raget




Groupama Team France inserting rudder stock for mounting. Note elevator (horizontal portion of the T) in protective covering.  Photo:2015 ACEA/Gilles Martin-Raget





Ready to splash. Photo:2015 ACEA/Gilles Martin-Raget




Close-up of mounted foiling rudder.
Photo:2015 ACEA/Gilles Martin-Raget



SoftBank Team Japan's Chris Draper adjusting rig tension.
Photo:2015 ACEA/Gilles Martin-Raget
